Product Code:PP192C
The Machine is a high-sensitivity inspection system designed to detect and automatically remove ferrous and non-ferrous metal contaminants from packaged products.
Related Video
Suitable for flat and large-arc surface labeling on paper, cards, flat bags, folders, boxes, cartons, and round cans. Commonly used in electronics, food, pharmaceutical, and logistics industries.
Features
l Suitable for labeling on flat surface‚ large circular arc surface‚ such as paper‚ card‚ flat bags‚ folder‚ box and carton etc
l Mainly Stainless Steel 304 and High Class aluminum alloy construction
l Intelligent optic-electric detecting‚ no object no labeling interlock
l Stepper motor driven‚ optic-electric sensing‚ and unique label driving mechanism‚ enhance the precision of labeling
l PLC with touch screen control
l Easy change over design
l Separating device and outfeed magazine
for automatic separation and collection of thin sheet‑type products
l Integrated thermal transfer printer
enables variable data printing simultaneously with labeling
l Top pressing mechanism
ensures more stable labeling, ideal for corner-fold applications or taller products
l Vacuum label pick-up and placement
for top-side labeling, ensuring smooth label application
l Bottom pick-up and labeling mechanism
specially designed for bottom-side labeling
Advantages
l High Precision: Labeling accuracy up to ±1 mm (subject to product and label tolerances), meeting high‑standard packaging requirement
l High Efficiency: Speeds up to 200 labels/min (depending on model and product size), effectively improving production line throughput
l Reliable Performance: Stepper motor and photoelectric sensing, combined with all-stainless-steel construction, ensure stable long-term operation
l Flexible Adaptation: Multiple infeed options (belt/page-feeding), labeling directions (top/bottom/corner), and optional add-ons allow customisation for diverse applications
Technical Specification
Catalogue/1J-T-XXX | 301A | 301B | 301C |
Number of Label | 1 / top side | ||
Width of Label(mm) | 20 – 120 | 20 – 175 | 20 – 150 |
Length of Label(mm) | 20 – 400 | 6 – 250 | 6 – 250 |
Labeling Speed | 40 – 150 labels/min | 40-200 labels/min | 19 m/minute, 40-150 labels/min |
labeling Tolerance | ±1 mm | ||
Dimension of Products | L/40-400mm‚ W/40-200mm‚ H/20-150mm | L/60-250mm, W/60-220mm, H/0.2-20mm | L/30-280mm, W/40-100mm, H/30-200mm |
Power Supply | AC 220V 50/60Hz, 500W | ||
Catalogue/1J-T-XXX | 301D | 301BP | 301F |
Number of Label | 1 / top side | ||
Width of Label(mm) | 15 – 175 | 20 – 175 | 20 – 120 |
Length of Label(mm) | 20 – 320 | 6 – 250 | 20 – 400 |
Labeling Speed | 30-60 labels/min | 40-200 labels/min | 30-80 labels/min |
labeling Tolerance | ±1 mm | ||
Dimension of Products | W/D/25-100mm, H/25-230mm | L/60-250mm, W/60-220mm, H/0.2-20mm | L/40-400mm‚ W/40-200mm‚ H/20-150mm |
Power Supply | AC 220V 50/60Hz, 500W | ||
